CAD Work – AquaGreens

Designs, models, renders and construction documents created for Aqua Greens, a high-end floating golf green company. For further information on these specialty greens, please visit http://www.aquagreens.com

GUITAR-NECK_All-Turf

guitar-neck-built

SBO-Aerial-1-002

Kid-Rock-green-working-scaled

guitar-rock

Virginia_Dock-view-1_PS

dock-assemble

dock-complete

Visualization render of palm-themed aqua range. Models built in AutoCAD, 3ds Max render. Composited into photo using Photoshop. For Aquagreens.

Dual-palm green render.

Developed process to determine accurate float loading of greens, using Inventor.

Dual-palm green nears completion.

Single palm themed kidney.

Palm green range installed.

Shield theme aqua range visualization.

Visualization of green with complex surface. AutoCAD model, 3ds Max render, composited in Photoshop.

Designed with Jack Nicklaus Jr.

Construction blueprint for complex green showing elevation profiles at specified intervals. AutoCAD.

Complex green during install.

Complex green installed on customer's pond.

Visualization of kidney green in customer's pond.

Visualization of kidney green from shoreline.

"Splat" freeform green render.

Michigan themed green with graffiti siding concept.

Michigan themed green with old barnwood siding concept.

Visualization of Texas-themed green for Red Bull.

Photo from Red Bull event.

Spade shaped green visualization render, for casino.

Spade shaped green installed at Jumer's casino lake.

3ds Max render showing giant tee driving platform concept, for Red Bull "Boardwalk Drive" event.

Tee in use on Revel casino, overlooking Atlantic City boardwalk.

Iso view of golf tee interior structure, part of blueprint package, for Aquagreens. AutoCAD.

Visualization of green for U.S. Open promotion, Daytona Speedway.

Green in use at Daytona.

Render of concept for travelling wiffle ball stadium, for corporate promotion.

Gate concept drawings.

Gate elevation concept design blueprint, for Aquagreens. AutoCAD.

Completed gate.

Daytona Speedway visualization of golf event concept.

nike-island-one-sand-trap

Concept visualization of floating greens re-purposed as camping islands. For Aquagreens.

camping-swampy

camping-boardwalk-example

Concept for Hawaii Volcano themed green.

Concept for floating greens re-purposed for personal use islands.

Red Bull Frozen One

can-course-taper

Can-islands

Concept for tropical themed green for resort use.
